IP Video calling panel MIP-300 Black 1B
Code: 1644Product detailed description
The MIP-300 Black 1B is a stylish high-tech IP video calling panel with a built-in wide-angle video camera and infrared illumination for video recording in low light conditions. The device is equipped with a microphone and a speaker for voice communication with the visitor. The door lock is controlled by the built-in relay. The vandal proof housing of the calling panel is made of metal; it has protection against penetration of dust and moisture. Mоdel is equipped with mounting kit.
Main Features
Resolution: 1.0Mp (1280x720@25)
Lens: Fixed focus, f=1.9 mm. Wide viewing angle
Night vision: Up to 3 m
Card reader: Mifare
Horizontal / Vertical angle of view: 110° / 83°
Call button: 1 pcs.
Housing material: Solid metal
Housing protection: IP65. Complete dust and moisture protection. For outdoor or industrial use
Power supply: POE (single-cable transmission of video signal and power supply) or DC 12V, 0.2A
Dimensions: 210х116х32 mm, 1100 g
Operating temperature: -40 - 60 °C
Additional advantages:
— Built-in colour HD camera
— Built-in Mifare card and tag reader with controller
— Individual use
— Weatherproof panel (IP65)
— Night vision up to 3m
— Relay lock control
— Mounting kit
— 2 years warranty
Download MIP-300 Black 1B Datasheet Attention!
- Only qualified technician should be authorized to service this equipment.
- Avoid placing the device near sources of strong electromagnetic radiation.
- Do not install the device in places exposed to direct sunlight, rain, extremely high temperatures, high humidity levels, high dust levels and aggressive chemicals.
- The most appropriate place to install the device is at the level of the user's eyes.
- Prior to installation and removal of the device please make sure that the power supply is off.
- Install the device at least 30cm away from the power supply lines to avoid interference.
- Avoid ingress of moisture, foreign particles, and insects into the device enclosure.
Additional parameters
| Category: | IP Video Door Intercoms |
|---|---|
| Weight: | 0.74 kg |
| EAN: | 5061099730471 |
| Card reader standard: | Mifare |
| Housing material: | Solid metal |
| Housing protection: | IP65 |
| Lens: | Fixed focus\, f=1.9 mm |
| Night vision: | Up to 3 meters |
| Operating temperature: | '-40 - 60 °C |
