IP Video calling panel MIP-100MU Silver Myers
Code: 1435Product detailed description
The MIP-100MU Silver is a stylish high-tech IP video calling panel with a built-in wide-angle video camera and infrared illumination for video recording in low light conditions. The device is equipped with a microphone and a speaker for voice communication with the visitor. The door lock is controlled by the built-in relay. The vandal proof housing of the calling panel is made of metal; it has protection against penetration of dust and moisture. This model is equipped with mounting kit.
Main Features
Resolution:
1.0Mp (1280x720@25)
Lens:
Fixed focus, f=1.9 mm. Wide viewing angle
Night vision:
Up to 3 m
Horizontal / Vertical angle of view:
130° / 83°
Card reader:
Mifare
Built-in keypad:
Authentication method:
Card/tag, Code, Card/tag Code
Number of independent users:
254 pcs
Housing material:
Solid metal
Housing protection:
IP53
Power supply:
POE (single-cable transmission of video signal and power supply) or DC 12V, 0.2A
Dimensions:
365х137х48 mm, 1980 g
Operating temperature:
-40 - 60 °C
Additional advantages:
— Built-in colour HD camera
— Built-in Mifare card and tag reader with controller
— Built-in keypad
— For multi apartment use
— Weatherproof design (IP53)
— Night vision up to 3m
— Relay lock contro
— Mounting kit
- Only qualified technician should be authorized to service this equipment.
- Avoid placing the device near sources of strong electromagnetic radiation.
- Do not install the device in places exposed to direct sunlight, rain, extremely high temperatures, high humidity levels, high dust levels and aggressive chemicals.
- The most appropriate place to install the device is at the level of the user's eyes.
- Prior to installation and removal of the device please make sure that the power supply is off.
- Install the device at least 30cm away from the power supply lines to avoid interference.
- Avoid ingress of moisture, foreign particles, and insects into the device enclosure.
Additional parameters
| Category: | IP Video Door Intercoms |
|---|---|
| Weight: | 1.79 kg |
| EAN: | 5060491861820 |
| Card reader standard: | Mifare |
| Housing material: | Solid metal |
| Housing protection: | IP53 |
| Lens: | Fixed focus\, f=1.9 mm |
| Night vision: | Up to 3 meters |
| Operating temperature: | '-40 - 60 °C |
